Repairing a Lawnmower Cord

Category Lawn Mowers
When your pull cord is broken, won't pull smoothly or retract properly, you need a repair. This is a guide about repairing a lawnmower cord.
Ad

Solutions

Share on ThriftyFunThis guide contains the following solutions. Have something to add? Please share your solution!

November 11, 20161 found this helpful

This is a guide about lawnmower cord won't retract. It is frustrating when getting ready to mow your lawn to have the mower cord fail to retract.

Read More... Was this helpful? 1

February 24, 20170 found this helpful

If the pull cord on your mower gets stuck, you may be able to open up the mower and repair or replace it yourself. The other option is to find a repair shop. This is a guide about lawn mower starter cord won't pull.

Read More... Was this helpful? Yes
Ad

February 24, 20170 found this helpful

Replacing the pull cord on a mower can be done at home, but is not always that easy. This is a guide about broken pull cord on gas mower.

Read More... Was this helpful? Yes

Questions

Ask a QuestionHere are the questions asked by community members. Read on to see the answers provided by the ThriftyFun community or ask a new question.

By 0 found this helpful
April 28, 2009

The starter pull cord on my lawnmower is a bit too long for my arm, so the mower is hard for me to start up. What can I do to simplify this? It's the only reason I dislike mowing!

By Bsvgs from Big Bend, WV

Ad

Answers

May 3, 20090 found this helpful

Look in the end of the knob, there should be a hole where the end of the cord is knotted. You can pull the knob lower on the cord and re-knot it, thus shortening the cord.

Reply Was this helpful? Yes
May 4, 20090 found this helpful

Or, you can make a series of knots along the shaft of the cord. This makes things shorter. good luck!

Reply Was this helpful? Yes
May 7, 20090 found this helpful

Thanks, guy. I'll try the suggestions, as soon as the rain lets up around here in WV. Nica

Reply Was this helpful? Yes
Answer this Question...

By 0 found this helpful
May 16, 2010

I have an advanced lawn mower issue. My wife loves to mow anything and everything. She has apparently hit something with the mower and now it barely pulls, and when it pulls sometimes it snaps back like to pull your arm out of its socket. Underneath the blade just spins free. It's a Sears hand mower about 4 years old.

Ad

My dad usually helps me with these sorts of issues, but he died last fall. Any help is appreciated. I am handy and can fix this if I can get the parts and have an idea how bad this really is.

By JohnnyU from Baltimore, MD

Answers

May 17, 20100 found this helpful

Ours did the same thing. Turns out that the shaft was bent when we ran over something. Repair cost more than the mower was worth, so we had to get a new mower.

Reply Was this helpful? Yes
May 21, 20100 found this helpful

The shaft may be bent, but before you take the mower in for repair, check to see if the metal key that locks the flywheel to the shaft is broken. This is a DIY job. Remove the piece covering the flywheel, then remove the flywheel (you may need to buy an inexpensive tool to loosen the flywheel from the shaft). If the key is broken, simply replace it and reassemble everything.

Ad

Depending on how old the mower is, there may (probably will) be an automatic braking device that locks the flywheel and prevents the blade from spinning if the "dead man's" safety bar is released. Be sure that everything is put back the way it was before replacing the cover.

You should also check to see if the blade hub key is broken. Again, it's a simple DIY replacement.

Reply Was this helpful? Yes
Answer this Question...

By 0 found this helpful
April 27, 2010

I have a 22 inch Bolens pushmower I got at Lowe's last year. This year, the pull cord snapped and I had to replace it. While replacing the cord, I also took the blade off and sharpened it, and also changed the plug.

Ad



When I put the shroud back on and pulled the cord to start the mower, the flywheel only spins about half way around and stops. If I pull it easily, the cord will come all the way out and flywheel spins. When I pull hard to start it, it spins and stops. Nothing is blocking the blade, I do have the tank primed and the safety lever is squeezed.

Any ideas on why this happens?

By Doug from Springfield, IL

Answers

April 28, 20100 found this helpful

Take it back to Lowe's, good luck.

Reply Was this helpful? Yes
May 1, 20100 found this helpful

Hi, I've been a small engine tech for about 20 years.
Just a couple of questions that may help me help you.

1. Is this a Briggs and stratton Engine?
2. Did you rewind the recoil spring before installing the rope?

Reply Was this helpful? Yes
Answer this Question...

By 0 found this helpful
May 18, 2017

What does it mean when the pull string works off the mower, but not on the mower?

Answers

May 19, 20171 found this helpful

From YouTube: If you didn't find anything blocking the blade, you might have a problem with the recoil starter or the engine might be locked up. ... Disconnect the spark plug again and release the starter rope from the lawn mower handle. Remove the screws from the blower housing and pull the housing off the engine.

Reply Was this helpful? 1
Answer this Question...

By 0 found this helpful
May 16, 2016

I have an old 3hp Briggs lawnmower and the pull rope won't retract properly. I took the shroud off to take a look and I can fix it, but I am worried about the recoil spring popping out. How do I fix this without the spring being touched?

Answers

August 18, 20170 found this helpful

You have to remove the old cord, remove the rewinder unit, put in the new cord and replace the rewinder unit. Here is an article with photos:https://www.goo … broken-cord/amp/

Reply Was this helpful? Yes
Answer this Question...

By 0 found this helpful
August 5, 2010

The pull cord on my gas lawn mower has been replaced by a service technician three times. Why does the cord keep breaking?

By Teri

Answers

December 22, 20120 found this helpful

Is the cord rubbing on something sharp?

Reply Was this helpful? Yes
Answer this Question...

By 0 found this helpful
September 3, 2009

I was just outside using my lawnmower on my yard which hasn't been cut recently. It was way longer than I should have been keeping it. While I was going through my backyard it quit. Multiple times.

At first I couldn't pull the cord and found out that was due to there being too much grass caught in the blade. Then I continued to cut and then it quit on me again. I thought there was more grass underneath so I lifted it up and looked underneath and it was all clear. I tried to start it again and could pull the cord just fine, but after trying to pull it over 20 times now it still hasn't started back up.

I need help. I also don't know much about fixing things so if you answer please try and put it in simple terms for me.

By clay from Jacksonville, FL

Answers

September 3, 20090 found this helpful

Could be a multitude of things; bad/old gasoline; spark plug needs replacing; debris in fuel line; if you've checked these things, your only hope is to locate a small engine repair service locally.
http://www.rust … ower-repair.html

Reply Was this helpful? Yes
Answer this Question...

By 0 found this helpful
July 22, 2015

I have a 3 yr old Husqvarna selfpropelled lawn mower. I try to pull the rope to start and it won't pull out at all. I can turn the blade by hand, but can't by rope. So what can cause this?

Answer this Question...

March 16, 20150 found this helpful

When trying to start my self propelled mower the recoil is massive! I hurt my hand and my chest when the cord snapped back. Any help?

By Billy P.

Answer this Question...

March 15, 20150 found this helpful

I have a lawn machine, Briggs and Stratton 550ex, pushmower. The carb was replaced by the manufacturer. It was returned and now the pull cable gets stuck. I took the cover off and tried to turn by hand. It stops, then gets stuck. What's wrong? Something is blocking it from turning. I checked the handles and they are where they are suppose to be. The safety cable, throttle, etc. are all attached properly. Any thoughts?

By john r

Answer this Question...

By 0 found this helpful
April 13, 2011

I pulled the string on my self propelled lawn mower and it just turns. Is this normal or do I have to do something?

By Jesus from PA

Answer this Question...

Archives

ThriftyFun is one of the longest running frugal living communities on the Internet. These are archives of older discussions.

September 3, 20090 found this helpful

The pull string on the lawnmower is pulling and retracting okay, but with no resistance. Therefore it is not generating any spark at the plug. Anybody have an idea of how to fix it? It is a Briggs and Stratton engine. Many thanks.

Richard from Wales

Answers:

Pull String Not Starting Lawnmower

Hi. The ears are probably broken inside the housing for the pull starter that actually causes the starter to engage with the flywheel. Take off the housing and replace the locking unit. Should not be too expensive. (06/08/2009)

By jdj599

Comment Was this helpful? Yes
